Grizzly Scalpers

AGGRETEK pan feeders with grizzly scalper have been designed for the most difficult conditions and applications. Various grizzly bar options make our feeders suitable for primary separation applications. Compact and high capacity with an effective grizzly design and a second deck allows for effectively liberating more fines.

FEATURES

HEAVY-DUTY VIBRATING SCREENS
The output material of the primary group may need to be screened in accordance with the installation plan. In these cases, standard vibrating screens may not meet the required capacity and can be disadvantageous in respect to servicing costs, but the top decks of our heavy-duty screens are equipped with grizzly or abrasion resistant perforated plates to avoid any damage caused by large-size materials. The springs on heavy-duty screens are more durable as well.

Wide range of applications with grizzly bars, durable heat-treated drive console and high quality vibrators

PROVEN QUALITY VIBRATORS
The vibrators used on our feeders are of internationally approved quality, and serve to increase feeder performance to the highest level. The frequency of these vibrators is adjustable through the control panel, making it very easy to maintain the grizzly feeder’s performance at peak levels according to the nature of the rock being crushed.

IMPERIAL

AGS 1276
W x L / Feeder
feet
43x15
W x L / Scalper
feet
47x10
F(Feeder) S(Scalper)
HP
F: 2x15
S: 2x15
Capacity
stph
220-330
Maximum Feed Size
inch
32
AGS 1480
W x L / Feeder
feet
55x16
W x L / Scalper
feet
55x10
F(Feeder) S(Scalper)
HP
F: 2x20
S: 2x20
Capacity
stph
330-550
Maximum Feed Size
inch
36
AGS 1880
W x L / Feeder
feet
71x16
W x L / Scalper
feet
71x10
F(Feeder) S(Scalper)
HP
F: 2x20
S: 2x20
Capacity
stph
880-1320
Maximum Feed Size
inch
47

METRIC

AGS 1276
W x L / Feeder
mm
1100x4600
W x L / Scalper
mm
1200x3000
F(Feeder) S(Scalper)
kW
F: 2x7.5
S: 2x7.5
Capacity
mtph
200-300
Maximum Feed Size
mm
800
AGS 1480
W x L / Feeder
mm
1400x5000
W x L / Scalper
mm
1400x3000
F(Feeder) S(Scalper)
kW
F: 2x9
S: 2x9
Capacity
mtph
300-500
Maximum Feed Size
mm
900
AGS 1880
W x L / Feeder
mm
1800x5000
W x L / Scalper
mm
1900x3000
F(Feeder) S(Scalper)
kW
F: 2x14
S: 2x14
Capacity
mtph
800-1200
Maximum Feed Size
mm
1200

Make the Competition See Red

Our expertise stems from the many years of working with the largest aggregate companies in the world and having seen almost every application for aggregate machinery out there.

From the building of machinery in the early years we know what works and what doesn’t. From our extensive time in the field with producers, we have a strong understanding of what is required to keep an end user profitable, and we are always available to assist.
